    12V Li-ion / LiFePO4 Battery BMS Board Protection Circuit Module 4S 100A 150A PCM Type

    Ask Lasest Price
    Brand Name : ENERKEY
    Model Number : JW-4S150A-779
    Supply Ability : 50000 Piece/Pieces per Month
    Price : $32.80/pieces 2-999 pieces
    Certification : ISO9001/ROHS/CE
    • Product Details
    • Company Profile

    12V Li-ion / LiFePO4 Battery BMS Board Protection Circuit Module 4S 100A 150A PCM Type

    Enerkey Smart BMS Protection Circuit Module 4S 100A 150A BMS for 12V Li-ion/LiFePO4 Battery BMS Board
    Product Description
    Electric Parameter
    Model: JW-B4S150A-779
    NO.
    Project
    Min.
    Typ.
    Max.
    Unit
    1
    Voltage
    Balance voltage for single cell
    3.175
    3.200
    3.225
    V
    2
    Current
    Balance current for single cell
    50
    55
    60
    mA
    Current consumption
    70
    uA
    Maximal continuous charging current
    100
    A
    Maximal continuous discharging current
    100
    A
    3
    Over charge protection
    Overcharge detection voltage for single cell
    3.625
    3.75
    3.775
    A
    Overcharge detection delay time
    500
    1500
    mS
    Overcharge release voltage for single cell
    3.50
    3.55
    3.60
    V
    4
    Over discharge protection
    Overdischarge detection voltage for single cell
    2.25
    2.30
    2.35
    V
    Overdischarge detection delay time
    500
    1500
    mS
    Overdischarge release voltage for single cell
    2.4
    2.5
    2.6
    V
    5
    Overcurrent protection
    Over discharge current protection
    230
    280
    330
    mS
    Detection delay time 1
    500
    1500
    mS
    Detection delay time 2
    500
    1500
    mS
    Overcharge current protects current
    100
    500
    A
    Detection delay time
    500
    1500
    mS
    6
    Short circuit protection
    Short circuit protection current
    500
    A
    Detection delay time
    50
    800
    μS
    Protection condition
    Exterior short circuit
    Release condition
    Cut load,Auto recovery
    7
    Resistance
    The on-state resistance of the main circuit
    5
    8
    Temperature Protection
    Charging high temperature protection
    50
    55
    60
    Charge low temperature protection
    0
    Discharge high temperature protection
    70
    75
    80
    Discharge low temperature protection
    -20
    -15
    -10
    Release condition
    The temperature drops to 50ºC, charge release
    9
    Temperature
    Operating Temperature Range
    -20
    /
    60
    Storage Temperature Range
    -20
    /
    60
    10
    Break circuit protection
    Disconnect the voltage sampling circuit to turn off the charge and discharge
    Support
    11
    NTC Protection
    Thermistor temperature protection
    Support
    12
    Electronic switch
    Electronic switch
    Nonsupport
    13
    Reverse polarity protection
    Support
    Function Details
    1. Provides protection for 4 series LiFePO4 battery pack
    2. Provides protections in charging and discharging
    3. Processes the balance between cells smartly, the current of it can be set freely by external components.
    4. Deals with over-current and short-circuit protection with circuit itself
    5. Protect an electrical circuit from damage caused by over current/ over load or short circuit
    6. Support SMBUS protocol
    7. Support Bluetooth protocol
    12V Li-ion / LiFePO4 Battery BMS Board Protection Circuit Module 4S 100A 150A PCM Type
    Wiring precautions
    First connect the B- of the BMS to the total negative terminal of the battery pack, Wiring B-, B1, B2... B+, output charge and discharge negative electrode connected to P-, charge and discharge positive electrode connected to the total positive electrode, please wire connection strictly according to the drawing and use thick cable to connect with P+/ C+/ B+ and P-/ C-
