Electric Drill Modification Ternary Lithium Battery BMS with Peak Starting Current 60A

Product Description

Product Name :	Lithium Battery BMS
Product model:	EK-B3S12A
Unit quantity:	3S
Brand :	Enerkey
Product size :	L56 x W40 x T4(mm)

Electric Parameter
NO.	Project			Min.	Typ.	Max.	Unit
1	Parameter	Rated operating voltage B+ B-			12.6	V
			Rated discharge current		12		A
			Peak starting current		60		A
2	Overcharge protection	P+P- Input withstand voltage			33	V
			Charge detection voltage	4.225	4.280	4.305	V
			Charge detection delay time	0.5	1	1.5	S
			Overcharge release voltage	4.030	4.050	4.130	V
3	Overdischarge protection	Discharge detection voltage	2.17	2.50	2.33	V
			Discharge detection delay time		100		ms
			Discharge release voltage	2.85	2.95	3.05	V
			Protection release condition	Disconnect external load or charge self-recovery
4	Overcurrent protection	Overcurrent detects voltage		0.1		V
			Overcurrent protection the current		20		A
			Overcurrent detection delay time		100		ms
			Protection release condition	Disconnect external load or charge self-recovery
5	Short-circuit protection	Short-circuit protection current		60		A
			Short-circuit detection delay time	150	250	400	μS
			Short-circuit protection release condition	Disconnect external load or charge self-recovery
6	Resistance	Main circuit on-state resistance		6	9	mΩ
7	Consumption current	Usually the operation consumes current		5	9	μA
8	Quiescent current	Current consumed during sleep			0.1	μA
9	Operating temperature	_	-40	25	85	℃

Product Use Tutorial

Packing&Shipping

Shipment
Quantity (PCS)	1-10	11-500	501-5000	＞5000
Lead Times (days)	2	7	30	To be negotiated

Normally it will take 10-45days to arrive, the speed of customs clearance & shipping in buyers country that decides it arrive faster or delay,please understand.
