The Intelligent Active Balancer is a balance management system
tailored for large capacity series battery packs.
This equalizer uses supercapacitors as the medium to achieve active
energy transfer equalization.
Real-Time Monitoring: Continuous monitoring of voltage and
temperature helps identify issues early, improving safety and
reliability.
Scalability: Suitable for integration into larger systems, allowing
for flexible scaling in various applications.
User Configurability: Customizable settings enable tailored
operation based on specific requirements, enhancing versatility.
Safety Features: Built-in protections against over-voltage,
under-voltage, and overheating ensure safe operation.
Technical Parameters
| Product model | 16S 2A 4A Smart Active Balancer for 2-16s (EK-16S2/4EB) |
| Supported battery type | NCM / LFP(Li-ion/Lifepo4) |
| Single cell voltage collection range | |
| Undervoltage protects sleep voltage | APP can be customized Settings :1.5-4.2V |
| Equilibrium method | Time-sharing single channel transfer, point-to-point energy
transfer |
| Reverse protection | Support disorderly power on detection/protection |
| Equilibrium current | APP can be customized Settings: 1A~2A(2A version) APP can be customized Settings: 1A~4A(4A version) |
| Whether an external power supply is required | When the total battery system voltage is below 24V,
An external booster module or an external power supply is required. |
| Voltage equalization accuracy | APP can be customized Settings :1mV(TYP) |
| Wire cascading | |
| Power failure detection function | |
| Wrong wire protection function | |
| Fault alarm function | |
| Buzzer | APP can be customized Settings |
| Power dissipation | At equilibrium≈1W,Stop equilibrium≈0.5W |
| Operating temperature | |
Application
| Electric toys, electric balance car/bicycle |
Packing List
Use Manual
Wiring Diagram
EK-16S4EB supports cascading use, and at least one battery between
every two equalizers is the "common end of energy exchange". The
following uses the 32S as an example to describe how to install and
connect cables:
Notice:
1.When used in cascade, there is at least one "energy exchange
commonend" between every two equalizers. When welding, please note
whetherthe connection here is correct.
2.During cascading use, please check whether the wiring is
wrongrepeatedly.lf it cannot be used after connection, please
contactafter-sales personnel to consult the corresponding cascade
diagram.
